Features

• 24V class 2 control circuit with 40VA transformer to protect against short circuit
• External radio control terminal strip
• Low friction powder metal limit cam nuts with fully adjustable rotary limit switches
• Three button open-close-stop control station Nema-1
• 1/2HP high starting torque, instant reversible motor protected by internal automatic thermal overload device
• Heavy duty 4LV-belt
• #41 roller chain and sprockets on all internal drives
• Adjustable friction clutch
• 3/4" permanently lubricated and sealed ball bearings on pulley shaft
• 1" permanently lubricated and sealed bearings on final drive shaft
• Solenoid brake standard
• Emergency disconnect with electrical cut-out switch for manual operation
• Chain keeper
• Left or right hand mounting
• #41 roller chain and sprockets on final drive
• Baked on dark grey coat finish
• Shipping wight 65 lbs

1

• Heavy duty relays incorporating the new UL325 (2010) Interface Module.
• *C2 factory wiring standard (constant pressure close), B2 wiring can be field set by moving 1 jumper and installing Micanan compatible monitored fail safe photo-eyes (supplied) or (optional) Micanan compatible monitored fail safe electric edge.

2

• Heavy duty relays (Not available in US or other areas where UL325 (2010) is mandated)
• *C2 factory wiring standard (constant pressure close), B2 wiring can be field set by moving 1 jumper. Provisions for standard reversing devices.
